Signage Solutions Video Wall Display

55BDL2105X/00

Signage Solutions Video Wall Display

55BDL2105X/00

Make an impact

Designed for 24/7 operation, the Philips X-Line Videowall display captivates customer attention with its immersive moving content. CMND makes managing your promotions and retail content easy, whilst FailOver adds greater peace of mind.

Signage Solutions Video Wall Display

Make an impact

Designed for 24/7 operation, the Philips X-Line Videowall display captivates customer attention with its immersive moving content. CMND makes managing your promotions and retail content easy, whilst FailOver adds greater peace of mind.

Make an impact

Designed for 24/7 operation, the Philips X-Line Videowall display captivates customer attention with its immersive moving content. CMND makes managing your promotions and retail content easy, whilst FailOver adds greater peace of mind.

Signage Solutions Video Wall Display

Make an impact

Designed for 24/7 operation, the Philips X-Line Videowall display captivates customer attention with its immersive moving content. CMND makes managing your promotions and retail content easy, whilst FailOver adds greater peace of mind.

Make an impact

Spectacular retail experiences all day and night

  • 55"
  • Direct LED Backlight
  • Full HD
  • 500cd/m²
Operate, monitor and maintain with CMND & Control

Operate, monitor and maintain with CMND & Control

Run your display network over a local (LAN) connection. CMND & Control allows you to perform vital functions like controlling inputs and monitoring display status. Whether you're in charge of one screen or 100.

FailOver ensures content is always playing

FailOver ensures content is always playing

From waiting room to meeting room, never show a blank screen. FailOver lets your Philips Professional Display switch automatically between primary and secondary inputs ensuring content keeps playing even if the primary source goes down. Simply set a list of alternate inputs to be sure your business is always on.

OPS slot allows for PC embedding without cabling

OPS slot allows for PC embedding without cabling

Integrate a full-power PC or Android-powered CRD50 module directly into your Philips Professional Display. The OPS slot contains all the connections you need to run your slot-in solution, including a power supply.

Add Android processing power with an optional CRD50 module

Embed an Android System-on-Chip (SoC) in your Philips Professional Display. The optional CRD50 module is an OPS device that enables Android processing power without the need for cables. Simply slide into the OPS slot, which contains all the connections needed to run the module (including power supply).

Tiling mode. Create tiled 4K videowalls of any size

Connect two or more Philips professional displays to create a tiled videowall-without the need for external devices. A single player takes care of content, whether you have four screens or 40. 4K content is fully supported, and if you're showing that content on four screens you get the best possible dot-by-dot resolution.

Ultra-narrow bezels. For distraction-free images

Boost image quality with Pure Colour Pro. Delivering higher luminance through custom colour temperature settings and advanced gamma calibration, content looks crisper and more radiant for stunning realism with a visual pop.

Technical Specifications

  • Picture/Display

    Diagonal screen size (metric)
    138.7  cm
    Diagonal screen size (inch)
    54.5  inch
    Panel resolution
    1920x1080p
    Optimum resolution
    1920 x 1080 @ 60 Hz
    Brightness
    500  cd/m²
    Dynamic contrast ratio
    500,000:1
    Response time (typical)
    8  ms
    Aspect ratio
    16:9
    Viewing angle (horizontal)
    178  degree
    Viewing angle (vertical)
    178  degree
    Pixel pitch
    0.63 x 0.63 mm
    Display colors
    16.7 M
    Contrast ratio (typical)
    1200:1
    Haze
    25 %
  • Supported Display Resolution

    Computer formats
    • 720 x 400, 70Hz
    • 800 x 600, 60, 75Hz
    • 1024 x 768, 60, 75Hz
    • 1280 x 768, 60Hz
    • 1280 x 800, 60Hz
    • 1280 x 960, 60Hz
    • 1280 x 1024, 60Hz
    • 1360 x 768, 60Hz
    • 1366 x 768, 60Hz
    • 1600 x 1200, 60Hz
    • 1920 x 1080, 60Hz
    • 640 x 480, 60, 72, 75Hz
    Video formats
    • 720p, 50, 60Hz
    • 1080i, 25, 30Hz
    • 1080p, 50, 60Hz
  • Connectivity

    Video input
    • Display Port1.2 (x1)
    • DVI-D (x1)
    • HDMI 2.0 (x2)
    • VGA (Analog D-Sub) (x1)
    Audio input
    3.5 mm mini jack (x1)
    Video output
    DisplayPort 1.2 (x1)
    Audio output
    3.5 mm Mini Jack (x1)
    External control
    • IR (in) 3.5 mm jack
    • LAN RJ45 (x2)
    • RS232 (in/out) RJ45
    Other connections
    • OPS
    • USB 2.0 (x1)
    • Thermal sensor
  • Convenience

    Placement
    • Landscape (24/7)
    • Portrait (24/7)
    Tiled Matrix
    Up to 15 x 15
    Screen saving functions
    Pixel Shift, Low Bright
    Signal loop through
    • DisplayPort
    • RJ45
    Ease of installation
    • Carrying Handles
    • Smart Insert
    Energy saving functions
    Smart Power
    Network controllable
    LAN (RJ45)
  • Operating conditions

    Temperature range (operation)
    0 ~ 40  °C
    Temperature range (storage)
    -20 ~ 60  °C
    Altitude
    0 ~ 3000 m
    MTBF
    50,000  hour(s)
    Humidity range (operation)[RH]
    20 - 80% (without condensation)
    Humidity range (storage) [RH]
    5 - 95% (without condensation)
  • Power

    Consumption (Typical)
    180  W
    Consumption (Max)
    340 W
    Consumption (On mode)
    140 W
    Standby power consumption
    0.5 W
    Energy Label Class
    G
  • Sound

    Built-in speakers
    2 x 10W (RMS)
  • Accessories

    Included Accessories
    • Gap pad x3
    • IR sensor cable (1.8 m) (x1)
    • Quick start guide (x1)
    • Remote control & AAA batteries
    • RJ45 / RS232 converter
    • Wire Clamper (x3)
    • Power cord
    • DP cable (x1)
    • RJ45 cable (x1)
    • Edge alignment pin (x2)
    • Kit-1 (x1)
    • Kit-2 (x2)
  • Miscellaneous

    On-Screen Display Languages
    • Arabic
    • English
    • French
    • German
    • Italian
    • Japanese
    • Polish
    • Russian
    • Spanish
    • Simplified Chinese
    • Turkish
    • Traditional Chinese
    Regulatory approvals
    • CE
    • FCC, Class A
    • RoHS
    • CB
    • ETL
    • BSMI
    Warranty
    3 years warranty
  • Dimensions

    Smart Insert mount
    100mm x 100mm, 6xM4xL6
    Set Width
    1213.5  mm
    Set Height
    684.3  mm
    Set Depth
    97.8 mm(D@WallMount)/97.8 mm(D@Handle)  mm
    Set Width (inch)
    47.77  inch
    Set Height (inch)
    26.94  inch
    Set Depth (inch)
    3.85 (D@WallMount)/3.85 (D@Handle)  inch
    Bezel width
    2.3 mm + 1.2 mm
    Wall Mount
    400mm x 400mm, M6
    Product weight
    28.8  kg
